Wireless

Wireless for 10Gig

CIG Wireless Access Products meet the rigorous requirements of the enterprise and residential markets, where a typical network consists of Routers/Gateways, Data Switches with PoE, Wireless Access Points (Wireless APs) , AC controllers, and LTE 4G/5G Small Cells.

Our wireless network products include indoor APs, outdoor APs, outdoor CPE, 4G/5G Small Cells.

Main function and applications of the Wireless APs are to provide wireless access and interconnection to devices including mobile phones, tablets, laptops, cameras, and others. Our products are widely deployed in enterprises (offices, hotels, etc.), public locations and residences around the world.

Featured Products

  • 10Gig over WI-FI(MLO)

    Low latency

    Optimized for AR and Gaming

  • Desktop placement

    2.4GHz 40MHz 2×2 802.11b/g/n/ac/ax

    5GHz 160MHz 4×4 802.11a/n/ac/ax

    6GHz 160MHz 2×2 802.11ax

    WPA2/WPA3 PSK security

    BLE 5.0

    Integrated antennas

    1 x 2.5GbE WAN

    1 x GE RJ45 LAN

    1 x Status LED (multi-color)

    1 x USB-C PD AC adapter

    OpenSync™ Certification (Home Pass & Work Pass)

    Integrated with Plume Cloud Management and Plume Mobile Management Applications

  • Desktop placement

    2.4GHz 2×2 802.11b/g/n

    5GHz 4×4 802.11a/n/ac

    WPA/WPA2-PSK(AES)

    BLE 5.0

    6 x Integrated Wi-Fi antennas

    1 x Integrated BLE antennas

    1 x GE RJ45 LAN

    1 x Status LED (multi-color)

    1 x AC/ DC power supply

    Supports Opensync™ control plane

    Integrated with Plume Cloud management

    Integrated with Plume mobile management application (Android and iOS)

10Gig Router

Wi-Fi Mesh

  • Desktop placement

    2.4GHz 40MHz 2×2 802.11b/g/n/ac/ax

    5GHz 160MHz band 4×4 802.11a/n/ac/ax

    WPA2/WPA3 PSK security

    BLE 5.0

    Integrated antennas

    1 x 2.5GbE WAN

    1 x GE RJ45 LAN

    1 x Status LED (multi-color)

    1 x USB-C PD AC adapter

    OpenSyncTM Certification(Homepass & Workpass)

    Integrated with Plume Cloud management and Plume Mobile Management Applications

  • DeskPod Ultra WF-810

    Highest performance at 7.8Gbps aggregate throughput (AX7800)

    2.4GHz 40MHz 2×2 802.11b/g/n/ac/ax

    5GHz 160MHz low band 2×2 802.11a/n/ac/ax

    5GHz 160MHz high band 4×4 802.11a/n/ac/ax

    WPA/WPA2-PSK(AES)/WPA3

    BLE 5.0

    7 x Integrated Wi-Fi antennas

    1 x Integrated BLE antennas

    1 x 2.5GbE WAN

    1 x GE RJ45 LAN

    1 x Status LED (multi-color)

    1 x USB-C PD AC adapter

    Supports OpenSync™control plane

    Integrated with Plume Cloud management and Plume Mobile Management Application

  • Supports pole and wall mounting

    Supports 2.4G 2×2/40MHz Wi-Fi(802.11b/g/n/ac/ax),up to 574Mbps link rate

    Supports 5G 2×2/ 80MHz Wi-Fi(802.11a/ n/ ac/ ax), up to 1.2Gbps link rate

    Supports BLE 5.0

    Supports GPS

    2 x Dual-band Integrated 120-degree directional antennas (5dBi@2.4G, 7dBi @5GHz)

    1 x Integrated Bluetooth antenna

    1 x 2.5GE WAN, with 802.3 af/ at PoE (PD)

    1x Reset Button

    1x RBG LEDs for visual indication

    Supports OpenWiFi development platform

  • Supports wall mounting with universal bracket

    Supports 2.4G 2×2/ 40MHz Wi-Fi (802.11b/ g/ n/ ac/ ax), up to 574Mbps link rate

    Supports 5G 2×2/ 160MHz Wi-Fi(802.11a/ n/ ac/ ax), up to 2.4Gbps link rate

    Supports BLE 5.1/ Zigbee

    2 x Integrated dual-band antennas

    1 x Integrated Bluetooth antenna

    1 x GE WAN, on the device back, with 802.3af PoE (PD)

    2 x RJ45 GbE LAN

    1 x Reset Button, on the sid

    1x RBG LEDs for visual indication

Enterprise AP

  • Ceiling mounting and wall mounting

    2.4G 4×4 Wi-Fi (802.11b/g/n/ac/ax ), 20/ 40MHz

    5G 4×4 Wi-Fi (802.11a/n/ac/ax), 20/ 40/ 80MHz

    6G 4×4 Wi-Fi (802.11ax), 20/ 40/ 80/ 160MHz

    4 x dual-band 2.4G/5G Integrated antennas

    4 x 6G Integrated single-band antennas

    1 x BLE integrated antenna

    1 x Bluetooth 5.0/ Zigbee

    1 x 2.5GbE LAN

    1 x 5GE WAN, with 802.3 at/ bt PoE(PD)

    1 x Reset button

    1 x RGB LED for visual indicators

    USB type-C PD (30W, 15V@2A or 12V@3A)

    Supports OpenWiFi development platform

  • Supports wall mounting with universal bracket

    Supports 2.4G 2×2/ 40MHz Wi-Fi (802.11b/ g/ n/ ac/ ax), up to 574Mbps link rate

    Supports 5G 2×2/ 160MHz Wi-Fi(802.11a/ n/ ac/ ax), up to 2.4Gbps link rate

    Supports BLE 5.1/ Zigbee

    2 x Integrated dual-band antennas

    1 x Integrated Bluetooth antenna

    1 x GE WAN, on the device back

    ** Operates with 802.3bt PoE (PD), with 802.3af PoE (PSE) working

    ** Operates with 802.3af PoE (PD), without 802.3af PoE (PSE) working

    4x RJ45 GbE LAN, LAN4 with 802.3af PoE out

    1 x Reset Button, on the side

    1x RBG LEDs for visual indication

  • Supports ceiling and wall mounting

    Supports 2.4G 2×2/ 40MHz Wi-Fi (802.11b/ g/ n/ ac/ ax), up to 574Mbps link rate

    Supports 5G 2×2/ 80MHz Wi-Fi(802.11a/ n/ ac/ ax), up to 1.2Gbps link rate

    Supports BLE 5.0

    2 x Integrated dual-band antennas

    1 x Integrated Bluetooth antenn

    1 x GE WAN, with 802.3af PoE(PD)

    1 x GE LAN

    1 x Reset button1 x DC Jack, supports 12VDC power supply

    4x LEDs for visual indication

    Supports OpenWiFi development platform

  • Small Cell All-in-One

    5G & 4G

    Modular gNB

    Multi-Mode

    Multi-Band

For More Information, Please Contact Us

Small Cell All-in-One

  • Details to be provided

O-RAN Radio

  • Split 7-2

For More Information, Please Contact Us

  • Split 7-2
